Azure Virtual Desktop: from POC to prod, the hardening checklist

TL;DR. A fully private AVD POC that works is not a prod. Between the two: harden the FSLogix storage (NTFS ACLs, backup), automate secret rotation, wire up observability (AVD Insights + dedicated LAW), scale the session hosts (custom image, sessionHostConfiguration), plan for DR (FSLogix GZRS / Cloud Cache) and enable the enterprise features (Conditional Access/MFA, Intune, App Attach). Here’s the ROI-prioritised roadmap, plus the POC’s technical debt to clear.

Published 22 June 2026. Follow-up to the article AVD in a Landing Zone retrospective. Stack: Terraform · Terragrunt · azurerm ~> 4.0 · FSLogix / Azure Files Premium · Windows 11 multi-session.

---

The POC is validated: AVD deployed in a spoke of a Landing Zone, zero public endpoint, FSLogix profiles on Entra Kerberos, Autoscale in place. But a POC optimises for “it works”, not for “it holds in prod”. Here’s what we add on top, in order of priority / ROI.

---

P1 — Hygiene & minimal security

NTFS ACLs on the FSLogix share

The profiles share is accessible over SMB via Entra Kerberos + the Storage File Data SMB Share Contributor RBAC. But at the NTFS level, everyone sees everyone else’s folders. You have to apply Microsoft’s recommended ACLs (from a session logged onto a session host):

icacls \\<storage>.file.core.windows.net\profiles `
  /inheritance:r `
  /grant "<domain>\<grp_avd_users>:(M)" `
  /grant "CREATOR OWNER:(OI)(CI)(IO)(M)" `
  /grant "BUILTIN\Administrators:(F)"

Automate it via a Custom Script Extension the first time, or a scheduled Azure Run Command.

Automatic Key Vault secret rotation

The session hosts’ local admin password and the FSLogix storage account key expire at 90 days. Today rotation is manual. To automate:

• Logic App triggered by Event Grid (event SecretNearExpiry), or
• Azure Function on a timer trigger,
• Action: az storage account keys renew + az keyvault secret set.

The module that manages the secrets has ignore_changes = [value] → out-of-band rotation doesn’t create Terraform drift.

Policy exemption for manual KV operations

Deny-PublicPaaS + a Key Vault with public_network_access_enabled = false means you have to be on the corp VPN to read/write a secret via the portal. Two options: a targeted policy exemption on the KV’s RG (with justification + expiry date), or maintaining public access restricted by firewall ACLs (IP allowlist) — at the risk the policy refuses it.

Activity log + diagnostic settings

No route to Log Analytics today. For each critical resource (host pool, workspace, session host), enable the diagnostic settings → LAW.

---

P2 — Observability

AVD Insights (dedicated LAW)

Microsoft recommends a dedicated AVD Log Analytics Workspace. To create:

• law-avd (30-day retention in POC, 90-day in prod),
• a DCR (Data Collection Rule) with the perf counters + event logs Insights requires,
• the DCR ↔ session hosts association,
• the host pool / workspace / app group diagnostic settings → LAW,
• the AVD Insights workbook.

On the IaC side, this translates into new Terragrunt deployments: law-avd/, dcr-avd/, the dcra-avd/ association, and the diag-*-avd/. Indicative cost: LAW ingestion ~€2–3/GB; for a low-usage session host, budget ~€10/month.

Action groups + AMBA alerts

The scaling plan events, session host agent failures and storage quota thresholds can be surfaced via Azure Monitor Baseline Alerts. The Landing Zone already provides a base — it remains to add the AVD-specific alerts.

---

P3 — Scalability

Multiple session hosts

Go from 1 to 3+ session hosts to test a BreadthFirst load balancing + a realistic Autoscale ramp-up. Points of attention:

• Availability zones: the module spreads automatically across zones 1/2/3.
• NSG: verify the inbound/outbound rules scale.
• FSLogix: 1 container per user; a share supports ~3000 concurrent users before you need to consider multi-share sharding.

The new sessionHostConfiguration pattern

Today we manage the session hosts via a VM counter + extensions. Microsoft introduced the sessionHostConfiguration pattern (a host pool sub-resource, in preview at the time of writing) that automates create/update/scale of the VMs: no more individual extension management, automatic image update, integration with dynamic Autoscale. To check: its GA status and the azurerm version that supports it.

Custom image (Shared Image Gallery)

Today we start from the Marketplace image win11-24h2-avd. To standardise with the business apps pre-installed:

1. Create a template VM, install the apps + the config.
2. Sysprep + generalize.
3. Capture the image in a Shared Image Gallery.
4. Azure Image Builder to automate the build + monthly patching.
5. Point the session host module at the custom image.

---

P4 — Prod deployment

Prod subscription

The subscription ID placeholder for the prod AVD must be replaced by the real ID once the subscription is provisioned, then:

export TG_ENV="prod"
cd landing-zone/corporate/avd
terragrunt run-all apply

Variables to double-check between prod and nprd:

• FSLogix quota: size by the number of users (~30 GiB/user typical).
• number of session hosts: baseline + provision for the peak.
• VM size: D4ds_v5 or more for heavy users (Office, Teams, IDE).
• ramp_down_force_logoff_users: switch to true to actually shut the VMs down at end of day (in POC it’s false for testing).
• locks on all the RGs (not just network + KV).

DR / secondary region

The AVD control plane is automatically redundant on the Microsoft side (multi-region metadata). On the user data side (FSLogix):

• GZRS on Azure Files (cross-region replication), or
• FSLogix Cloud Cache (replication between two storage accounts in two regions).

The session hosts don’t need DR: they are stateless (all user state lives in FSLogix).

---

P5 — Enterprise features

MFA / Conditional Access

Enforce MFA on the AVD connection via an Entra ID Conditional Access policy targeting the Azure Virtual Desktop application (Microsoft public appId 9cdead84-a844-4324-93f2-b2e6bb768d07). The AzureAD provider handles this with azuread_conditional_access_policy.

Automatic Intune enrollment

Entra-joined session hosts can auto-enroll into Intune (policies, software deployment, compliance) — via the mdmId support on the AADLoginForWindows extension.

RDP Shortpath, session recording, App Attach

• RDP Shortpath (UDP, lower latency): Shortpath for managed networks (UDP port 3390) works in a full-private design — over the private UDP path, enabled with the Allow Direct UDP network path over Private Link opt-in. Only Shortpath for public networks (STUN/TURN) isn’t supported with Private Link. Worth enabling the managed-networks path against a real perf need.
• Session recording (audit/compliance): Microsoft Purview (in preview) or third-party solutions. Not a POC priority.
• App Attach / MSIX: package the business apps as MSIX and attach them dynamically to the session host rather than freezing them in the image → lighter image + app versioning.

---

The POC’s technical debt to clear

• shared_access_key_enabled = true on the FSLogix storage — enabled so Terraform can manage the share via the data plane. To harden in prod: disable the shared key, give the Terragrunt SP the right role to manage the shares via the control plane, and switch the provider to storage_use_azuread = true.
• No FSLogix backup — no backup of the VHDX containers. ZRS protects against a zone failure, not against human error or deletion. Plan for Azure Backup for Azure Files (or scheduled snapshots).
• No FSLogix horizontal scaling — a single storage account for all profiles. Beyond ~3000 concurrent users, plan for multi-account sharding (FSLogix CCDLocations / split by AD group).
• Non-IaC DNS resolution — the client-side NRPT and the privatelink-global.wvd.microsoft.com zone wire are manual. To industrialise: a custom ALZ Deploy-Private-DNS-AVD-Global policy that auto-wires the zone group when a global PE is detected, or a conditional ignore_changes on the PE module.

---

None of these evolutions is blocking to demonstrate AVD’s value. But between a POC that runs and a regulated prod that holds, it’s precisely this list that makes the difference — and sorting it by ROI avoids trying to do everything at once.
