Azure Virtual Desktop in a regulated Landing Zone: the traps no doc tells you about

TL;DR. Deploying Azure Virtual Desktop fully private in a Landing Zone (Private Endpoints everywhere, Palo Alto NVA for egress, centralised DNS) works very well — once you know about a dozen traps that are written nowhere clearly. The control plane necessarily lives in a different region from the session hosts. rdweb.wvd.microsoft.com doesn’t resolve without a dedicated global Private Endpoint. Entra Kerberos has a race condition on the first apply. Entra-joined session hosts silently refuse legacy RDP auth. And 70% of the cost of a POC is FSLogix Premium storage, not compute.

Published 20 June 2026. Stack: Terraform · Terragrunt · azurerm ~> 4.0 · azapi · Windows 11 25H2 multi-session (M365 Apps) · FSLogix + Azure Files Premium ZRS (Entra Kerberos) · regions germanywestcentral (data plane) + westeurope (control plane).

---

The context

AVD deployed in a spoke of an Azure Landing Zone, for compliant virtual desktops:

• Control plane (host pool, workspaces, application group, scaling plan) in westeurope.
• Data plane (Win11 multi-session session hosts, FSLogix, Key Vault) in germanywestcentral.
• Zero public endpoint: Private Endpoints on the workspace (feed + global), the host pool (connection), Azure Files (FSLogix) and the Key Vault.
• Session host Internet egress via UDR 0.0.0.0/0 → Palo Alto NVA. Private DNS zones centralised in the hub, wired by the ALZ DINE policies.
• User profiles on FSLogix (VHDX containers) with Entra Kerberos authentication on Azure Files Premium ZRS.

What follows isn’t a tutorial. These are the non-obvious learnings — the ones that cost you hours and that you won’t find by searching the error in a search engine.

---

Network & control plane

The control plane necessarily lives in a different region from the session hosts

For a deployment in germanywestcentral, the AVD control plane (host pool, workspace, app group, scaling plan) must live in westeurope — the nearest supported region. The session hosts, FSLogix and the PEs stay in GWC.

This isn’t a performance compromise: the control plane is only metadata. The data plane (RDP sessions, profiles) never crosses the regional boundary. But it forces you to:

• Split the naming (-gwc- vs -weu-) by component.
• Override location + region_code in the Terragrunt units of the control-plane components.
• Accept that one resource group hosts WEU resources in a subscription declared “primary” in GWC.

Takeaway: a subscription has no primary region — each resource group has its own. Counter-intuitive, but perfectly valid on the Azure side.

rdweb.wvd.microsoft.com doesn’t resolve without the global PE

This is trap #1 that breaks the final UX. Everything else is OK (workspace, host pool, user RBAC), but the Windows App client shows “No devices or apps found” because the initial feed discovery fails.

The hub’s Private DNS Resolver resolves the privatelink.* zones and forwards the rest. But with a VPN NRPT that catch-alls . to the Palo’s DNS proxy, rdweb.wvd.microsoft.com requests (a public Microsoft record) can be blocked or not forwarded depending on the firewall config.

The solution is architectural: deploy a Private Endpoint for the global subresource on a dedicated placeholder workspace with no application groups attached. Microsoft then CNAMEs rdweb.wvd.microsoft.com → a private record in privatelink-global.wvd.microsoft.com. Everything stays private.

Careful: this global workspace is a tenant-wide singleton — a single global PE for the whole AVD fleet. Deleting that workspace breaks feed discovery for every deployment in the tenant. If there are other AVD deployments elsewhere, you have to coordinate.

DINE policies only cover the standard subresources

The ALZ Deploy-Private-DNS-* policies auto-wire the feed and connection subresources into the privatelink.wvd.microsoft.com zone (a deployedByPolicy group appears on its own on the PE).

But the global subresource (zone privatelink-global.wvd.microsoft.com, newer on the Microsoft side) has no equivalent policy assigned. The PE is created fine, but no zone group → records absent → resolution impossible.

For every new type of PE introduced, verify the DINE exists:

az network private-endpoint dns-zone-group list \
  --resource-group <rg> --endpoint-name <pe> -o table

If the list is empty after a few minutes, wire the zone group manually.

The scaling plan needs the subscription scope

“Unable to access host pool” error when creating the scaling plan, even though the Desktop Virtualization Power On Off Contributor role was assigned on the VMs’ resource group. The naive logic — “the role is on the VMs, that’s enough for start/stop” — is wrong.

The AVD service principal must read the host pool (in WEU, in another RG) to orchestrate the start/stop of the VMs (in GWC). Since the two are in different resource groups, the minimum viable scope is the subscription.

Takeaway for Autoscale: subscription scope, not resource group. It’s in the Microsoft docs, but easy to miss when you optimise for least-privilege.

---

Identity & authentication

Entra Kerberos: a race condition on the first apply

Symptom: NotFound: The resource '.../applications/<guid>' does not exist when creating a storage account with directory_type = "AADKERB".

No corresponding Entra object exists (verified via az ad app/sp list). It’s the Azure backend that keeps a reference to a Graph application supposedly created by a previous failed apply — a phantom reference, in neither Entra nor any visible resource. No cleanup possible on the user side.

Workaround: create the storage account without AADKERB (commenting out the block), then a 2nd apply that adds the block → Azure cleanly reinitialises and creates a fresh service principal.

Takeaway: for services that auto-create Entra objects (Storage AADKERB, Managed HSM…), a first apply that fails midway can leave phantom references. The 2-phase pattern is the generic solution.

The DSC token goes through PrivateSettingsRef, not in cleartext

Naively, you put the registrationInfoToken in protected_settings.properties. Error: “duplicate arguments”. If you remove it from the public block, another error.

The truth: Microsoft’s DSC script expects a pscredential, not a string. You need this pattern:

settings.properties.registrationInfoTokenCredential = {
  UserName = "PLACEHOLDER_DO_NOT_USE"
  Password = "PrivateSettingsRef:RegistrationInfoToken"
}
protected_settings.Items.RegistrationInfoToken = <token>

Microsoft’s ARM examples use it everywhere, but no Terraform doc shows this pattern clearly. The PrivateSettingsRef:KEY reference on the public side + Items.KEY on the protected side is a DSC convention inherited from WMF — really not intuitive.

Entra-joined session hosts silently refuse legacy RDP auth

The trap that costs you two hours after everything else works. RBAC OK, feed visible, click “Connect” → “Your credentials did not work” loop even with the right password.

The Windows App client sends a legacy NTLM auth by default. The Entra-joined session host refuses it — and the error message is misleading (it suggests a wrong password, not an authentication mismatch).

Fix: custom RDP properties on the host pool:

targetisaadjoined:i:1;enablerdsaadauth:i:1

enablerdsaadauth is the modern property: it makes the client authenticate to the host with Microsoft Entra ID (the web-account / WAM flow) and provides SSO — it replaces targetisaadjoined. targetisaadjoined is the legacy fallback it supersedes: it allows username/password connections to Entra-joined hosts from clients that don’t meet the modern requirements (non-Windows clients, or local Windows devices not joined to Entra). Setting both covers the modern SSO path plus the legacy fallback. No warning, no obvious doc.

---

Terraform & operations

The PE module’s ignore_changes hides the manual wire

The PrivateEndpoint module ignores changes on private_dns_zone_group — laudable intent: let ALZ DINE manage it without Terraform reverting.

But when the DINE does not wire it (the global subresource case) and you add the block in Terragrunt config, Terraform detects no diff (ignore_changes blinds it). The plan says “no changes” even though something is clearly missing.

Workarounds:

• terragrunt apply -replace='module.pe.azurerm_private_endpoint.this["xxx"]' → destroy/recreate with the new block (but the PE loses its IP in the process).
• az network private-endpoint dns-zone-group create fallback (one-shot; ignore_changes won’t touch anything after).

A better-designed module would have a conditional ignore_changes: ignore if the block is absent in config, manage if present. But Terraform doesn’t support dynamic ignore_changes — impossible natively.

A Key Vault’s data-plane rights don’t follow the control-plane

You can be Owner on the subscription (so full control-plane RBAC on the Key Vaults) and still hit Forbidden: getSecret/setSecret on data-plane operations. The first apply that tries to write a secret fails.

Owner on the sub gives administrative rights on the KVs (delete, lock, modify policies) but not read/write of the encrypted content. That’s Key Vault’s Zero Trust design, but it surprises. The KeyVaultStack module exposes an assign_rbac_to_current_user toggle that assigns Key Vault Administrator (data plane) to the deployer — enable it for bootstrap.

Key Vault recovered from soft-delete: never delete a PE connection by hand

A KV with purge_protection_enabled = true is never recreated from scratch: the azurerm provider recovers it from soft-delete. The recovered KV brings back its old Private Endpoint connection records — hence multiple entries (psc-…-001, …-001.2, …-001.3) in Rejected/Approved for a single deployed PE.

The trap: you can’t identify the live connection by its name or suffix. All entries point to the same privateEndpoint.id (the PE was recreated with the same name). Assuming “the most recent = the live one” is wrong. If you delete the wrong one, the PE goes Disconnected, loses its IP, and Azure does not know how to reconnect a disconnected PE.

Reliable cleanup = recreate the PE, not sort the connections:

terragrunt apply -replace='module.pe.azurerm_private_endpoint.this["this"]' --working-dir kv-avd

The -replace destroys the PE and its dead connection, recreates a fresh auto-approved one; the remaining orphans become harmless. Takeaway: on a soft-delete-recovered KV, orphaned PE connections are cosmetic — leave them, or recreate the PE. Never a targeted manual delete.

Windows note. terragrunt apply -replace='res.this["key"]' gets its quotes stripped by PowerShell 5.1 → “Invalid force-replace address”. Use the stop-parsing sigil --% (terragrunt --% apply -replace='…') or pass the address via a variable. Otherwise, run from bash.

---

Cost

70% of the cost of an AVD POC is FSLogix Premium storage

Order of magnitude for 1 D4s_v5 session host with weekday Autoscale:

Item	Monthly cost
Compute (session host)	~€50
OS disk	~€17
Azure Files Premium ZRS 500 GiB	~€104
Private Endpoints	~€32

Azure Files Premium is provisioned — you pay for the quota, not the usage. Provisioning 500 GiB for zero active users is €104 thrown away. The rule for a POC: start at the Premium minimum (100 GiB) and scale up later.

Takeaway: the cost of an AVD POC is driven first by the FSLogix quota, not by the VMs.

---

Meta-learning: deploy in onion order

The order of the phases isn’t arbitrary — each layer functionally depends on the previous one:

1. Network + storage identity — without this, nothing runs.
2. Data storage with auth — FSLogix ready to receive connections.
3. AVD control plane — the Azure-managed services.
4. Private Endpoints — the real private connectivity.
5. Compute + RBAC + scaling — the session hosts, which consume all the previous layers.

Skipping a step gives you a session host that boots but refuses to register to the host pool (missing PE), or that registers but can’t mount FSLogix (missing storage permission). Debugging becomes painful because the errors are at several levels at once.

Takeaway: deploy in onion order, verify each layer before moving to the next.

---

None of these points is a secret — they’re all somewhere in the Microsoft docs, scattered. But gathering them costs a whole POC. If you’re deploying AVD in a private Landing Zone, you just saved yourself a few days.
