Why I Don't Use AVM Modules As-Is (And What I Do Instead)

AVM Is Great — But Not For Everything

Azure Verified Modules are the gold standard for Terraform on Azure. Microsoft maintains them, they follow strict interface specs, and they cover an impressive range of resources. If you’re starting a greenfield project with standard Terraform, AVM is where you should begin.

But AVM modules are designed for broad reuse. They need to support every possible configuration, every edge case, every optional feature. The AKS AVM module alone has hundreds of variables. When you control the entire stack — when you know your region, your naming convention, your security posture — that flexibility becomes overhead.

The real value of AVM isn’t the modules themselves. It’s the patterns: how they structure variables, handle role assignments, manage locks, expose outputs. Those patterns are battle-tested and transferable. You can take them and build focused, opinionated modules that fit your architecture exactly.

That’s what I did. 60+ custom modules, all aligned with AVM conventions, tailored to a production Azure Landing Zone at POST Luxembourg.

The Terragrunt Problem

The decision to build custom modules wasn’t purely philosophical — it was forced by a hard technical constraint.

Terragrunt copies only the referenced module folder into its .terragrunt-cache directory. If your module calls a child module with a relative path (module "kv" { source = "../KeyVault" }), that sibling folder doesn’t exist in the cache. The plan fails with a “module not found” error.

This means you can’t compose modules in the traditional Terraform way. A “stack” module that wraps a Resource Group + Key Vault + Private Endpoint can’t call three child modules. It has to use resource blocks directly, duplicating the patterns from each individual module.

# KeyVaultStack/main.tf — resources directly, no child modules
# Note: KeyVault/PrivateEndpoint/ResourceGroup modules cannot be
#       called as child modules because Terragrunt only copies
#       the module folder into its cache.

resource "azurerm_resource_group" "this" {
  name     = local.rg_name
  location = var.location
  tags     = local.common_tags
}

resource "azurerm_key_vault" "this" {
  name                = local.kv_name
  location            = var.location
  resource_group_name = azurerm_resource_group.this.name
  tenant_id           = coalesce(var.tenant_id, data.azurerm_client_config.current.tenant_id)
  sku_name            = var.sku_name

  purge_protection_enabled      = true
  public_network_access_enabled = false

  lifecycle {
    prevent_destroy = true
  }
}

resource "azurerm_private_endpoint" "this" {
  name                = local.pe_name
  location            = var.location
  resource_group_name = azurerm_resource_group.this.name
  subnet_id           = var.subnet_id

  private_service_connection {
    name                           = "psc-${local.pe_name}"
    private_connection_resource_id = azurerm_key_vault.this.id
    subresource_names              = ["vault"]
    is_manual_connection           = false
  }

  lifecycle {
    ignore_changes = [private_dns_zone_group]
  }
}

Why not use a monorepo module?

You could put everything in a single module folder and reference it, but that defeats the purpose of modular design. The Terragrunt approach means each deployment (terragrunt.hcl) points to exactly one module, and that module contains everything it needs. The trade-off is duplication in stack modules — but the patterns stay consistent.

The 6 Patterns I Took From AVM

1. map(object) Instead of list(object)

This is the single most impactful pattern I adopted from AVM. With list(object), Terraform creates for_each keys from index positions or values. If a value comes from another module’s output (like a resource group ID), it’s unknown at plan time. Terraform can’t build the resource graph and the plan fails.

With map(object), the keys are arbitrary strings that you control. They’re always known at plan time, regardless of what the values resolve to.

Before:

# Before: list(object) — breaks when values are unknown at plan time
variable "role_assignments" {
  type = list(object({
    scope                = string
    role_definition_name = string
    principal_id         = string
  }))
}

# Usage with list — index keys depend on values
role_assignments = [
  { scope = dependency.rg.outputs.id, role_definition_name = "Reader", principal_id = "..." }
]

After:

# After: map(object) — keys are always known at plan time
variable "role_assignments" {
  type = map(object({
    role_definition_id_or_name = string
    principal_id               = string
    principal_type             = optional(string)
    condition                  = optional(string)
    condition_version          = optional(string)
    description                = optional(string)
  }))
  default  = {}
  nullable = false
}

# Usage with map — key "rg_reader" is always known
role_assignments = {
  rg_reader = {
    role_definition_id_or_name = "Reader"
    principal_id               = dependency.identity.outputs.principal_id
  }
}

12 modules were migrated from list(object) to map(object). It was the biggest breaking change in the library, but every module that accepts collections now uses maps. Role assignments, routes, subnets, peerings — all maps with arbitrary string keys.

2. role_definition_id_or_name + strcontains()

AVM modules use a single role_definition_id_or_name field instead of two mutually exclusive fields (role_definition_id and role_definition_name). The module auto-detects which one you passed by checking if the value contains the Azure role definition resource path:

locals {
  role_definition_resource_substring = "/providers/Microsoft.Authorization/roleDefinitions"
}

resource "azurerm_role_assignment" "this" {
  for_each = var.role_assignments

  scope        = each.value.scope
  principal_id = each.value.principal_id

  # Auto-detect: is it a role ID or a role name?
  role_definition_id = strcontains(
    lower(each.value.role_definition_id_or_name),
    lower(local.role_definition_resource_substring)
  ) ? each.value.role_definition_id_or_name : null

  role_definition_name = strcontains(
    lower(each.value.role_definition_id_or_name),
    lower(local.role_definition_resource_substring)
  ) ? null : each.value.role_definition_id_or_name
}

One field. No “you set both” or “you set neither” errors. The consumer passes "Reader" or a full role definition ID — the module figures it out. 7 modules use this pattern: KeyVault, KeyVaultStack, ResourceGroup, RbacAssignments, Aks, ContainerRegistry, and StorageAccount.

3. lock Variable

Every module that creates a lockable resource exposes the same lock variable — a standard object with kind (required) and name (optional):

variable "lock" {
  type = object({
    kind = string
    name = optional(string)
  })
  default     = null
  description = "Management lock. kind = CanNotDelete or ReadOnly."

  validation {
    condition     = var.lock != null ? contains(["CanNotDelete", "ReadOnly"], var.lock.kind) : true
    error_message = "Lock kind must be CanNotDelete or ReadOnly."
  }
}

resource "azurerm_management_lock" "this" {
  count = var.lock != null ? 1 : 0

  lock_level = var.lock.kind
  name       = coalesce(var.lock.name, "lock-${var.lock.kind}")
  scope      = azurerm_resource_group.this.id
}

Two options: CanNotDelete (prevent accidental deletion) or ReadOnly (prevent any modification). The name auto-generates if you don’t provide one. 8 modules gained lock support: ResourceGroup, KeyVault, KeyVaultStack, Aks, ContainerRegistry, StorageAccount, Vnet, and RouteTable.

4. nullable = false on Required Vars

In Terraform, a variable with no default is required — but the caller can still pass null. Without nullable = false, that null propagates silently through your module until it hits a resource argument that can’t handle it, producing a cryptic error far from the source.

variable "location" {
  type        = string
  description = "Azure region"
  nullable    = false     # <-- Catches null at plan time
}

variable "subscription_acronym" {
  type = string
  validation {
    condition     = can(regex("^[a-z]{2,5}$", var.subscription_acronym))
    error_message = "Must be 2-5 lowercase letters."
  }
}

variable "environment" {
  type = string
  validation {
    condition     = can(regex("^[a-z]{2,4}$", var.environment))
    error_message = "Must be 2-4 lowercase letters."
  }
}

With nullable = false, Terraform catches the null at plan time with a clear message: “The value of variable X cannot be null.” Applied to all 60+ modules on every variable that must have a value.

5. Validation Blocks Everywhere

Every module validates its inputs aggressively. Three categories:

• Regex on naming vars — subscription_acronym must be 2-5 lowercase letters, environment must be 2-4 lowercase letters, region_code must be 2-5 lowercase letters. Catches typos before they become misnamed resources.
• Contains for enums — SKU values, protocol types, access levels, lock kinds. No freeform strings where a finite set of values exists.
• Cross-field validation — The most powerful pattern. Example from RouteTable: if next_hop_type is VirtualAppliance, then next_hop_in_ip_address is required. And the reverse: if it’s not VirtualAppliance, the IP must be null.

variable "routes" {
  type = map(object({
    name                   = string
    address_prefix         = string
    next_hop_type          = string
    next_hop_in_ip_address = optional(string)
  }))
  default  = {}
  nullable = false

  # Enum validation
  validation {
    condition = alltrue([
      for r in var.routes : contains(
        ["VirtualNetworkGateway", "VnetLocal", "Internet", "VirtualAppliance", "None"],
        r.next_hop_type
      )
    ])
    error_message = "next_hop_type must be one of the allowed values."
  }

  # Cross-field validation
  validation {
    condition = alltrue([
      for r in var.routes :
      r.next_hop_type != "VirtualAppliance" || r.next_hop_in_ip_address != null
    ])
    error_message = "next_hop_in_ip_address is required when next_hop_type is VirtualAppliance."
  }
}

The goal: every invalid configuration should fail at terraform plan, not at terraform apply. No waiting 10 minutes for an ARM deployment to tell you your SKU is wrong.

6. output “resource” (Complete Object)

Every module exposes the full primary resource as output "resource". Instead of guessing which attributes consumers might need and creating individual outputs for each one, the complete object is available:

output "resource" {
  description = "The complete Key Vault resource object"
  value       = azurerm_key_vault.this
}

# Consumer can access ANY attribute without module changes:
# module.keyvault.resource.vault_uri
# module.keyvault.resource.tenant_id
# module.keyvault.resource.id

This eliminates “add output X” pull requests. If a consumer needs vault_uri, it’s already there. If they need tenant_id tomorrow, it’s already there. The individual convenience outputs (id, name) still exist for readability, but resource is the escape hatch that prevents module churn.

What I Didn’t Take From AVM

AVM defines several interface specifications that I deliberately chose not to implement:

• Telemetry (enable_telemetry) — AVM modules send anonymous usage data to Microsoft. These are internal modules for a single organization. No tracking needed.
• Diagnostic settings interface — AVM embeds diagnostic settings inside each module. I built a separate DiagnosticSettings module. Decoupled, reusable, independently deployable.
• Private endpoints interface — Same approach. A standalone PrivateEndpoint module rather than embedding PE configuration in every resource module. Exception: stack modules like KeyVaultStack include PEs directly because they can’t call child modules.
• Managed identities interface — Separate ManagedIdentity module. Identity creation and role assignment are distinct lifecycle concerns from the resource itself.
• Customer managed key interface — Inlined where needed (KeyVaultStack, PaloCluster) rather than standardized across all modules. Only two modules need CMK, so the abstraction doesn’t pay for itself.

The principle: if AVM embeds a cross-cutting concern into every module, I extract it into a dedicated module instead. Less duplication, clearer ownership, independent deployment.

The Security Defaults I Added

Every module ships with opinionated security defaults that go beyond what AVM provides. These aren’t optional — they’re the baseline:

Default	Modules	Why
prevent_destroy = true	KV, AKS, ACR, DDoS, Storage, Palo VMs	Accidental terraform destroy on these costs hours or money
ignore_changes = [private_dns_zone_group]	All Private Endpoints	ALZ DINE policy manages DNS zone groups — Terraform must not fight it
public_network_access_enabled = false	KV, ACR, Storage, AKS	Zero public endpoints by default
purge_protection_enabled = true	All Key Vaults	Irreversible once enabled, but required for CMK scenarios
rbac_authorization_enabled = true	All Key Vaults	RBAC over access policies — consistent with landing zone IAM model
soft_delete_retention_days = 90	All Key Vaults	Maximum retention for compliance

The pattern: secure by default, override explicitly. If you want public access, you set public_network_access_enabled = true and everyone in the code review knows exactly what’s happening.

Was It Worth It?

60+ modules. All consistent. Every module follows the same structure: version.tf, variables.tf, main.tf, output.tf. Every module uses the same naming convention, the same validation patterns, the same output structure.

• New module time: 30 minutes following the pattern. Copy the skeleton, adapt the resource, add validations. The conventions are so established that the structure writes itself.
• Breaking changes: Controlled. The list → map migration was the biggest one, affecting 12 modules. It required updating every terragrunt.hcl that consumed those modules. But it was a one-time cost that eliminated an entire category of plan-time errors.
• Review confidence: The full library was reviewed by an Azure Architect and a Palo Alto Security Architect. No structural issues found. The consistency made review efficient — once you understand one module, you understand all 60+.

The lesson

AVM is a reference architecture, not a dependency. Take the patterns that make your modules better — map(object), strcontains(), lock, nullable = false, validation blocks, output "resource" — and leave the rest. Your modules should serve your landing zone, not the other way around.

The full module library is open source:

View on GitHub →
