Deploying Azure Virtual Desktop End-to-End in a Landing Zone

TL;DR. This is the deployment walkthrough for a fully private, Entra-only Azure Virtual Desktop environment inside a regulated Azure Landing Zone. Pooled Windows 11 multi-session on a custom golden image (Azure Image Builder → private Compute Gallery), FSLogix profiles on Azure Files with Entra Kerberos, zero public endpoints (five Private Endpoints), the AVD control plane pinned to a supported region while the session hosts live next to the users, all deployed with Terraform + Terragrunt in a strict onion order. One step stays manual by design. Companion reads: the traps no doc tells you about and the POC-to-prod hardening checklist.

The what-goes-wrong is covered in the pitfalls article. This one is the how — the architecture, the build order, and the one manual step you can’t automate away.

The target

The goal was a compliant virtual desktop that a user reaches over the corporate VPN with no public exposure of anything:

Pooled Windows 11 25H2 multi-session on a custom gold image — the marketplace AVD M365 base (FSLogix, OneDrive and Teams already baked in) plus the tooling the users need, versioned in a private Compute Gallery.
Pure Entra ID identity — Entra-joined session hosts, no domain controllers, no hybrid.
FSLogix profiles on Azure Files Premium (ZRS) authenticated with Entra Kerberos (AADKERB).
Full Private Link — the workspace (feed + global), the host pool (connection), Azure Files and the Key Vault all sit behind Private Endpoints. Session host egress goes through the hub Palo Alto NVA.
Autoscale to shut the compute down outside working hours.

One architectural fact drives the whole layout: the AVD control plane isn’t available in every region. The session hosts run in germanywestcentral (close to the users), but the host pool / workspace / app groups / scaling plan metadata must live in a supported region — here westeurope. That split is metadata-only; no user data crosses the boundary and there’s no latency impact.

sub avd (Germany West Central data plane · West Europe control plane)

  RG network (GWC)        vnet spoke 10.239.5.0/24
                          ├─ snet-hosts        (session hosts)
                          ├─ snet-pe-avd       (3 AVD PEs)
                          ├─ snet-pe-storage   (FSLogix PE)
                          └─ snet-pe-kv        (Key Vault PE)
                          NSG per subnet + UDR 0.0.0.0/0 → Palo ILB

  RG image (GWC)          Compute Gallery — win11-avd-m365 gold image (built by AIB)
  RG fslogix (GWC)        Premium FileStorage ZRS, share 'profiles' + AADKERB
  RG kv (GWC)             Key Vault (Premium, RBAC, purge protection)
  RG sh (GWC)             session host VM(s), Entra-joined, Trusted Launch

  RG avd (WEU)            host pool · workspace · global workspace ·
                          desktop + RemoteApp groups · scaling plan   (metadata)

DNS resolution stays private end-to-end: the spoke’s custom DNS points at the Palo Alto ILB, which forwards to the Azure DNS Private Resolver, which answers from the private zones (privatelink.wvd.microsoft.com, privatelink-global.wvd.microsoft.com, privatelink.file.core.windows.net, privatelink.vaultcore.azure.net).

The network plan

One /24 spoke, four subnets — session hosts plus one subnet per Private Endpoint family:

vnet-avd-nprd-gwc-spoke          10.239.5.0/24
  snet-…-hosts                   10.239.5.0/26     session hosts
  snet-…-pe-avd                  10.239.5.64/28    3 AVD PEs (feed, global, connection)
  snet-…-pe-storage              10.239.5.80/28    FSLogix PE (file)
  snet-…-pe-kv                   10.239.5.96/28    Key Vault PE (vault)
  (reserve)                      10.239.5.112-255

Every subnet gets its own NSG, and a route table sends 0.0.0.0/0 to the Palo Alto ILB frontend. The spoke is peered bidirectionally with the connectivity hub. (Subnets are created with the azapi atomic pattern so the “subnet must have an NSG” Deny policy doesn’t block them.)

The build, phase by phase

Terragrunt resolves the dependency graph, so terragrunt run-all apply from the avd/ folder does the whole thing in the right order. But it’s worth understanding the onion — each layer functionally depends on the one below it, and one step in the middle is deliberately manual. After a refactor, the network and the resource groups are each one consolidated unit, and the data-plane Private Endpoints (Key Vault, Azure Files) and the user role grants are created inline with the resource they belong to.

Phase 1 — Foundations

export TG_ENV="nprd"
cd landing-zone/corporate/avd

terragrunt apply --working-dir resource-group   # every RG (GWC + WEU) + CanNotDelete locks, one apply
terragrunt apply --working-dir network          # vnet + DDoS + Network Watcher + 4 NSGs + route table (→ Palo ILB) + spoke↔hub peering, one apply

Nothing runs without the network and the resource groups. All the RGs — network, image, fslogix, kv, sh in GWC plus the control-plane RG in WEU — are declared once in resource-group, with delete locks on the ones that must not be torn down.

Phase 2 — Key Vault + FSLogix storage

terragrunt apply --working-dir kv-avd           # Key Vault Premium + PE 'vault' (inline)
terragrunt apply --working-dir st-avd-fslogix   # Premium FileStorage ZRS + share 'profiles' + AADKERB + PE 'file' (inline) + SMB grant (inline)

The one manual step — Entra admin consent. Enabling AADKERB on the storage account creates an Entra Enterprise Application ([Storage Account] <name>). An admin has to grant tenant admin consent on it once, in the portal. Terraform can create the storage account, but it can’t click “Grant admin consent” for you — and until someone does, Kerberos auth to the share won’t work. This is the only touch you can’t automate.

The Key Vault is Premium (HSM-backed keys later), RBAC-authorized, purge-protected, public access disabled. Then the secrets, which need both the Key Vault and the storage account to exist first:

terragrunt apply --working-dir secrets-avd      # local-admin password + FSLogix key, 90-day expiry

Phase 3 — Golden image (Azure Image Builder → Compute Gallery)

The session hosts don’t boot a marketplace SKU directly — they boot a custom image that we build, version and keep private:

terragrunt apply --working-dir id-image-builder # user-assigned identity AIB runs as
terragrunt apply --working-dir gallery-avd      # Compute Gallery + image definition 'win11-avd-m365-dev'
terragrunt apply --working-dir image-avd        # AIB template → build → distribute a version

The pieces:

id-image-builder — a user-assigned managed identity that Azure Image Builder (AIB) impersonates, with Contributor on the image RG (to write gallery versions) and on a bring-your-own staging RG (where AIB spins up its ephemeral build VM). Hardening later: swap Contributor for a scoped custom Image Builder role.
gallery-avd — an Azure Compute Gallery in the GWC image RG, co-located with the session hosts, holding one image definition (win11-avd-m365-dev, TrustedLaunchSupported to match the hosts). This is the stable versioning target.
image-avd — the AIB template. It starts from the same win11-25h2-avd-m365 marketplace base as before (so FSLogix / OneDrive / Teams stay baked in), then a PowerShell customizer layers the extra tooling (VS Code / Git / Azure Repos) on top. AIB builds in an isolated staging RG with no public IP — only the finished image version is distributed into the private gallery, replicated to germanywestcentral.

Builds are auto_run_enabled = false on purpose: this is a POC, so image builds are kicked off manually (or from a pipeline for the monthly rebuild), not on every apply.

Phase 4 — AVD control plane (West Europe)

terragrunt apply --working-dir hp-avd           # host pool (+ 48h registration token)
terragrunt apply --working-dir ws-avd-global    # dedicated placeholder workspace for global discovery
terragrunt apply --working-dir dag-desktop      # Desktop application group (+ inline user grant)
terragrunt apply --working-dir dag-app          # RemoteApp application group: Edge/Excel/OneDrive/Outlook/Teams/Word
terragrunt apply --working-dir ws-avd           # main workspace — applied AFTER the app groups

Two things worth calling out. First, there are two application groups: a full Desktop and a RemoteApp group publishing individual apps (Edge, Excel, OneDrive, Outlook, Teams, Word). Second, the main workspace is applied last — it adopts both app groups through its application_group_associations, so they have to exist first.

The ws-avd-global workspace is a dedicated placeholder that exists only to terminate the global (initial feed discovery) Private Endpoint. That global workspace is a tenant-wide singleton — deleting it breaks feed discovery for the whole AVD estate.

Phase 5 — Private Endpoints + session hosts

terragrunt apply --working-dir pe-avd-hp        # PE subresource 'connection'
terragrunt apply --working-dir pe-avd-ws        # PE subresource 'feed'
terragrunt apply --working-dir pe-avd-global    # PE subresource 'global' — DNS zone group wired by the unit itself

The global subresource used to be a manual chore: the ALZ DINE policies auto-wire the feed and connection subresources into privatelink.wvd.microsoft.com, but there’s no equivalent policy for the global zone (privatelink-global.wvd.microsoft.com), so the global PE landed with no DNS records and rdweb.wvd.microsoft.com never resolved — the client showed “No devices or apps found”. The pe-avd-global unit now wires that zone group explicitly, so it’s declarative and no longer a manual step. (The PE module’s ignore_changes on the DNS wiring is still a subtlety worth understanding — full story here.)

Then the session hosts, which consume every layer below — network, Key Vault, host pool, FSLogix, secrets, and the gallery image:

terragrunt apply --working-dir sh-avd           # NIC + Win11 VM (custom image) + 6 chained extensions + inline VM-login grant
terragrunt apply --working-dir scaling-plan     # scaling plan + host pool association
terragrunt apply --working-dir rbac-avd-autoscale  # AVD service principal role assignment (sub scope)

The session host is a D4as_v7, Entra-joined with a system-assigned managed identity, Trusted Launch + encryption at host. It boots from the gallery image via source_image_id = <definition>/versions/latest — which takes precedence over any marketplace image reference. A consequence worth knowing: when you publish a new image version and re-apply, the VM is rebuilt. That’s safe here because the hosts are stateless — profiles live in FSLogix — but users get logged off, so you roll image updates during the Autoscale off-peak window.

The host runs six chained extensions, and the order matters:

AADLoginForWindows — Entra join
AVDDscExtension — the AVD agent DSC, registers the host to the pool using the token
FslogixConfig — points FSLogix at the Azure Files share
AzureMonitorWindowsAgent — logs/metrics into the workspace
AzurePolicyforWindows — guest configuration / policy compliance
MDE.Windows — Defender for Endpoint onboarding

The first three are the boot-critical chain (join → register → profiles); the last three layer on monitoring, compliance and EDR.

Phase 6 — Governance

Independent of the AVD data path, and applied any time after network:

terragrunt apply --working-dir policy-assignments        # DINE VNet flow logs → central storage
terragrunt apply --working-dir policy-exemptions         # waivers on the session-host RG (stateless hosts)
terragrunt apply --working-dir security-center-workspace # Defender for Cloud → central Log Analytics

The exemptions matter more than they look: pooled session hosts are stateless and rebuilt on every image update, so blanket VM policies (change tracking, guest monitoring agents, hybrid-VM rules) don’t apply the way they would to a pet server — they’re waived deliberately on the session-host RG rather than left to fail.

The RBAC model

A user needs three separate group memberships to use AVD end-to-end. The permissions are orthogonal — one for feed discovery, one for OS login, one for the FSLogix profile — and missing any one produces a different, confusing failure:

Azure role	Scope	What it unlocks
Desktop Virtualization User	the Desktop + RemoteApp groups	See the desktop/apps in the client feed
Virtual Machine User Login	the session-host resource group	Entra sign-in on the VM
Storage File Data SMB Share Contributor	the FSLogix resource group	Read/write the FSLogix profile
Desktop Virtualization Power On Off Contributor	the subscription	Autoscale start/stop (service principal)

That last one is the AVD service principal, and it has to be at subscription scope — assign it any lower (RG, host pool, VM) and Autoscale silently stops working. It’s the only grant that lives in its own unit (rbac-avd-autoscale); the three user grants are declared inline with the resource they protect — the app-group grants in dag-desktop/dag-app, the VM-login grant in sh-avd, the SMB grant in st-avd-fslogix.

Autoscale

A weekday-only scaling plan (W. Europe Standard Time), BreadthFirst while ramping up and DepthFirst to consolidate on the way down:

Phase	Start	Behaviour
Ramp-up	07:00	Min 20% hosts on; add hosts when existing ones exceed 60% load
Peak	09:00	Full capacity, BreadthFirst spread
Ramp-down	17:00	DepthFirst, 30-min user notification, no forced logoff
Off-peak	19:00	DepthFirst, hosts off once `ZeroActiveSessions`

No weekend schedule → hosts stay off from Friday 19:00 to Monday 07:00. A excludeFromScaling tag pulls a VM out of Autoscale for maintenance.

Cost

For a single D4as_v7 session host, Autoscale weekdays 07:00–19:00 brings it from ≈€300/month (always-on) down to ≈€200/month:

Component	€/month
VM D4as_v7 (Autoscale, 12h × 5 days)	≈50
OS disk Premium P10 (128 GiB)	≈17
Azure Files Premium ZRS (500 GiB provisioned)	≈104
Private Endpoints (5)	≈32
Key Vault Premium	≈0
AVD control plane (host pool / workspaces / app groups / scaling plan)	0

The single biggest lever isn’t compute — it’s the provisioned FSLogix quota. Azure Files Premium bills on the quota you reserve, not what you use; dropping 500 GiB → 100 GiB saves ≈€83/month. Size it to real usage. (The image gallery adds only the storage of the replicated image versions — a few euros — since AIB’s build VM is ephemeral.)

What I had to build

The AVD-specific modules didn’t exist in the shared library, so this deployment contributed a family of them (and extended a few more), all following the same AVM-aligned conventions as the rest of the landing zone:

AvdHostPool — host pool + registration token
AvdWorkspace — workspace (used twice: main + global placeholder)
AvdApplicationGroup — app group + workspace association (used twice: Desktop + RemoteApp)
AvdSessionHost — NIC + Windows VM + the six chained extensions
AvdScalingPlan — Autoscale schedules + host pool associations
ComputeGallery — Azure Compute Gallery + image definition
AvdImageTemplate — the Azure Image Builder template + customizers + gallery distribution
ManagedIdentity — the user-assigned identity AIB runs as
KeyVault-Secrets — random-generated secrets with a time_offset-driven expiry
StorageAccount (extended) — file_shares, azure_files_authentication (AADKERB), inline file PE
RbacAssignments (extended) — principal_type so a single module handles Group / User / SP grants

The shape of it

Strip away the specifics and the pattern is simple: deploy in the order things depend on each other, and be explicit about the one thing you can’t automate. Foundations and identity first, then storage, then the golden image, then the control plane, then the private wiring, then the compute that consumes all of it — and governance alongside. The Entra admin consent on the FSLogix storage account is the only manual touch left; everything else, including the global DNS zone group that used to be hand-wired, is one terragrunt run-all apply.

If you’re standing up AVD in a private Landing Zone, this is the skeleton. For the sharp edges you’ll hit along the way, read the pitfalls; for what to add before calling it production, the hardening checklist.
